P100S Industrial Tablet (Android 14)
Next-Level Specs. Unstoppable Performance. All-Day Power. Effortless Experience.The Chainway P100S is the latest 4G industrial tablet designed for high performance. Its 10.95-inch display offers an immersive viewing experience, while Android 14 and a powerful CPU deliver seamless and efficient operation. Equipped with a 10,000mAh removable smart battery, it powers through even the longest shifts. With IP67 sealing, it’s touch enough to withstand the harshest environments. Whether in retail, logistics, warehousing, manufacturing, or beyond, the P100S is your trusted partner for efficient and reliable operations.
P100S Industrial Tablet (Android 14)
Next-Level Specs. Unstoppable Performance. All-Day Power. Effortless Experience.
The Chainway P100S is the latest 4G industrial tablet designed for high performance. Its 10.95-inch display offers an immersive viewing experience, while Android 14 and a powerful CPU deliver seamless and efficient operation. Equipped with a 10,000mAh removable smart battery, it powers through even the longest shifts. With IP67 sealing, it’s touch enough to withstand the harshest environments. Whether in retail, logistics, warehousing, manufacturing, or beyond, the P100S is your trusted partner for efficient and reliable operations.
features
functions
Specifications
Physical Characteristics
Dimensions
263.5 x 175.0 x 13.5 mm / 10.37 x 6.89 x 0.53 in. (for standard version)
Weight
802g / 28.29 oz. (for standard version)
Display
10.95, 1920x1200
Touch Panel
Corning Glass, multi-touch panel, gloves and wet hands supported
Power
10000mAh removable main battery with meter, support fast charge
Expansion Slot
1 PSAM card (optional); 1 slot for Nano SlM card, 1 slot for Nano SlM /TF card
Interfaces
USB 3.0 Type-C, OTG, support USB Type-C Digital Earphone
Audio
2 microphone, 2 speakers
Keypad
1 scan key, 1 power key, 1 volume keys (+/-), 2 virtual keys
Communication
WLAN
Support 802.11 a/b/g/n/ac, 2.4G/5G dual-band; Wi-Fi 6E (optional)
WWAN
2G: GSM:B2/B3/B5/B8
3G: WCDMA:B1/B2/B4/B5/B8
4G: TDD LTE: B34/B38/B39/B40/B41 190M
FDD LTE: B1/B2/B3/B4/B5/B7/B8/B12/B17/
B18/B20/B28ab
3G: WCDMA:B1/B2/B4/B5/B8
4G: TDD LTE: B34/B38/B39/B40/B41 190M
FDD LTE: B1/B2/B3/B4/B5/B7/B8/B12/B17/
B18/B20/B28ab
Bluetooth
Bluetooth V5.2, support Bluetooth headset
Vo-LTE
Support Vo-LTE HD video voice call Galileo
GNSS
GPS/AGPS, GLONASS, BeiDou, Galileo
Developing Environment
Operating System
Android 14
SDK
Chainway Software Development Kit
Language
Java
Tool
Eclipse/Android studio
Performance
CPU
Octa-core 2.2 GHz
RAM+ROM
4GB + 64GB / 8GB + 256GB (optional)
Expansion
Supports up to 512 GB Micro SD card
User Environment
Operating Temp
-4°F to 122°F / -20°C to 50°C
Storage Temp
-40°F to 158°F / -40°C to 70°C
Humidity
5% RH-95% RH (non condensing)
Drop Specification
MIL-STD-810H (SGS Test): Multiple 1.2 m / 3.94 ft. drops to concrete across the operating temperature range
Sealing
IP67 per lEC sealing specifications
ESD
±15 KV air discharge, ±8 KV conductive discharge
Barcode Scanning
Scan engine
Zebra SE4100, SE5500; CM60
1D Symbologies
UPC/EAN, Code128, Code39, Code93, Codell, interleaved 2 of 5, Discrete 2 of 5, chinese 2 of 5, Codabar, Msl, Rss,etc.
2D Symbologies
PDF417, MicroPDF417, composite, RsS, TLC-39Datamatrix, QR code, Micro QR code, Aztec, Maxicode;Postal Codes: Us PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KlX), etc.
Camera
Front Camera
5 MP
Rear Camera
13 MP Autofocus with flash
NFC
Frequency
13.56 MHZ
Protocol
IS014443A/B, IS015693, NFC-IP1, NFC-IP2, etc.
Chips
M1 card (s50, s70), CPU card, NFC tags, etc.
Range
2-4 cm
PSAM
Protocol
IS07816
Slots
1 PSAM card slot
Note
* This function is optional
