P100 AI 5G Industrial Tablet (Android 14)

Rugged Performance, Customized to Your Needs, Fueling Sustained Business Growth
P100 AI 5G Industrial Tablet (Android 14)
The Chainway P100 is a cutting-edge 5G industrial tablet featuring a 10.95 high-brightness HD display and an optional 2.6GHz octa-core CPU for enhanced user experience and extended product lifecycle. The chipset integrates AI computing capabilities, unlocking the potential of artificial intelligence to improve the accuracy and efficiency of tasks like decoding, speech recognition, and image recognition. Its robust 10,000mAh removable battery ensures continuous operations, while Wi-Fi 6 with fast roaming and 2x2 MIMO antennas enables seamless data transmission.
features
functions

Specifications

Physical Characteristics
Dimensions
263.5 x 175.0 x 13.5mm / 10.37 x 6.89 x 0.53in. (for standard version)
Weight
802g / 28.29oz. (for standard version)
Touch Panel
10.95”, 1920x1200
Power
10000mAh removable main battery with meter; Support fast charge
Notification
Sound, LED indicator
Expansion Slot
1 PSAM card (Optional), 1 slot for Nano SlM card 1 slot for Nano SlM / TF card
Interfaces
USB 3.0 Type-C, OTG, Support USB Type-C Digital Earphone
Audio
2 microphones, 2 speakers
Keypad
1 scan key, l power key, 2 volume keys (+/-), 2 virtual keys
Sensors
Gravity sensor, light sensor, proximity sensor, gyroscope (optional), geomagnetic sensor (optional)
Communication
WLAN
Support 802.11 a / b / g / n / ac / ax, 2.4G / 5G dual-band
2*2 MIMO antennas
WWAN (Europe, Asia)
2G: GSM B2 / B3 / B5 / B8
      CDMA 1XEVDO BCO, BC1
3G: WCDMA B1 / B2 / B5 / B8
4G: TDD LTE B34 / B38 / B39 / B40 / B41 (2496-2690) / B42 / B43
      FDD LTE B1 / B2 / B3 / B4 /
WWAN (America)
2G: GSM B2 / B3 / B5 / B8
      CDMA 1XEVDO BCO, BC1
3G: WCDMA B1 / B2 / B4 / B5
4G: TDD LTE B38/B41 (2496-2690)
      FDD LTE:B1 / B2 / B4 / B5 / B7 / B12 / B13 / B17 / B25 / B2
Bluetooth
Bluetooth V5.2, support Bluetooth headset
Vo-LTE
Support Vo-LTE HD video voice call
GNSS
GPS/AGPS,GLONASS, BeiDou, Galileo
Developing Environment
Operating System
Android 14
SDK
Chainway Software Development Kit
Language
Java
Tool
Eclipse / Android Studio
Performance
CPU
Octa-core, 2.4GHz
Octa-core, 2.6GHz (Optional)
RAM+ROM
4GB+64GB / 8GB+256GB (Optional)
Expansion
Supports up to 512GB Micro SD card
User Environment
Operating Temp
-20 °C to 50 °C / 4 °F to 122 °F
Storage Temp
-40 °C to 70 °C / -40 °F to 158 °F
Humidity
5% RH - 95% RH (non condensing)
Drop Specification
MIL-STD-810H (SGS Test): Multiple 1.2 m/3.94 ft. drops to concrete across the operating temperature range
Sealing
IP67 per lEC sealing specifications
ESD
±15KV air discharge, ±8KV conductive discharge
Barcode Scanning
Scan engine
Zebra: SE4100, SE5500; CM60
1D Symbologies
UPC / EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS etc.
2D Symbologies
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX) etc.
Camera
Front Camera
5 MP
Rear Camera
13 MP Autofocus with flash
NFC
Frequency
13.56MHz
Protocol
ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
Chips
M1 card (S50, S70), CPU card, NFC tags, etc.
Range
2-4cm
PSAM
Protocol
ISO7816
Slots
1 PSAM card slot
Note
* This function is optional
