R1 RFID Reader/Writer
Supports Multiple Protocol Standards With Excellent HF&UHF Performance
Chainway R1 is a newly launched high-performance RFID Reader/Writer. With integrated UHF RFID modules based on Impinj E310 chip and supports Impinj Gen2X, R1 offers excellent UHF RFID performance. Together with the support to HF RFID and PSAM, R1 is able to read/write a wider range of tags. Besides, it supports Windows/Linux SDK. All these make R1 can be widely used in various RFID applications such as logistics, access control, attendance, anti-counterfeiting and production process control.
features
functions
Specifications
Physical Characteristics
Dimensions
117 mm x 117 mm x 25 mm
Weight
170 g / 6.0 oz.
Notification
LED indicator, buzzer
Interfaces
USB Type-C
Cable
1.2 m
Power
Input Voltage
DC3.5-5.25V
UHF
5W@25dBm
HF
2 W
Standby
0.4 W
User Environment
Operating Temp
-25 ℃ to 65 ℃
Storage Temp
-40 ℃ to 85 ℃
Humidity
10% - 95%
UHF RFID
Engine
CM-3N module based on Impinj E310
Frequency
865-868 MHz / 920-925 MHz / 902-928 MHz
Impinj Gen2X
Supported
Protocol
ISO18000-6C/EPC C1G2
Antenna
Circular Polarized Antenna
Output Power
+5 dBm to +25 dBm adjustable
Accuracy：+/-1dB
Accuracy：+/-1dB
Max Read Range
15 cm
PSAM
Protocol
ISO7816 T=0, T=1
Slots
2 slots
HF RFID
Frequency
13.56 MHz
Protocol
ISO/IEC 14443A
ISO/IEC 14443B
ISO/IEC 15693
ISO/IEC 18000-3 mode 3/EPC class-1 HF
JIS X 6319-4
ISO/IEC 14443B
ISO/IEC 15693
ISO/IEC 18000-3 mode 3/EPC class-1 HF
JIS X 6319-4
Range
5 cm
