R3 Desktop RFID Reader
Perform Impressive RFID Reading and Writing
Chainway R3 is a newly-developed desktop UHF reader, supporting Impinj Gen2X. It is compatible with Windows/ Android/IOS applications, and enables short read distance within 50cm. Combined with high-efficiency collision processing algorithm, it delivers fast reading and writing of tags and maintains high identification rate as well. And it allows data transmission via Bluetooth, Type C USB. R3 can be deployed in retail collection, logistics, identity verification, smart parking, access control, anti-counterfeiting system, production process control, etc.
features
functions
Specifications
Physical Characteristics
Dimensions
318 mm × 318 mm × 20 mm
Weight
1133 g / 39.96 oz.
Indicator LED
Power
BT connection status
Working (flash when scanning tags)
BT connection status
Working (flash when scanning tags)
Port
USB Type-C
Power Supply
USB Type-C
Communication
Bluetooth
Bluetooth Low Energy (BLE) 4.0
USB Type C
USB connection to realize data transfer
Developing Environment
SDK
USB, Android /Windows
Bluetooth, Android / IOS
Bluetooth, Android / IOS
User Environment
Operating Temp
-20 °C to +50 °C
Storage Temp
-40 °C to +70 °C
Humidity
5%RH - 95%RH non condensing
Sealing
IP65
UHF RFID
Engine
CM310-4 module based on Impinj E310
CM510-4 module based on Impinj E510
CM510-4 module based on Impinj E510
Frequency
865-868 / 920-925 / 902-928 MHz ( custom-design for frequency band )
Impinj Gen2X
Supported
Protocol
EPC C1 GEN2 / ISO18000-6C
Output Power
1dBm-30dBm, 1dBm (Stepper)
Read Range
0- 50 cm
