R2 Bluetooth RFID Reader
Outstanding UHF CapabilityChainway R2 is a handheld bluetooth reader with superior RFID performance. It delivers superior UHF reading and writing capabilities, supports Impinj Gen2X for enhanced RFID performance. The device also supports barcode scanning and transmits data to the data center via Bluetooth with ease. With its versatility, the R2 is ideal for tasks in inventory management, asset management, inspection, and other applications.
R2 Bluetooth RFID Reader
Light and Stylish Design
Chainway R2 is a handheld bluetooth reader with superior RFID performance. It delivers superior UHF reading and writing capabilities, supports Impinj Gen2X for enhanced RFID performance. The device also supports barcode scanning and transmits data to the data center via Bluetooth with ease. With its versatility, the R2 is ideal for tasks in inventory management, asset management, inspection, and other applications.
features
functions
Specifications
Physical Characteristics
Dimensions
282 x 117.5 x 32mm / 11.10 x 4.63 x 1.26in.
Weight
334 g / 11.78oz. (with battery)
Display
1.77 inch, 128 x 160
Power
Battery specification: 5200 mAh
Standby: over 70 hours (keeping bluetooth connected)
Continuous use: up to 6 hours (UHF reading)
Charging time: 3-4 hours (with standard adaptor and USB cable)
Standby: over 70 hours (keeping bluetooth connected)
Continuous use: up to 6 hours (UHF reading)
Charging time: 3-4 hours (with standard adaptor and USB cable)
Buzzer
Support
Interfaces
USB Type-C
Indicator LED
Power, Work, Bluetooth
Colour
White
Product Material
Plastic
Communication
Bluetooth
Bluetooth Low Energy (BLE) 5.0
Developing Environment
SDK
Android / iOS
Language
Java / Objective-C
Tool
Android Studio / Xcode
User Environment
Operating Temp
-20℃~+50℃
Storage Temp
-40℃~+70℃
Humidity
5%RH - 95%RH non condensing
Drop Specification
Multiple 1.5m / 4.9ft. drops (at least 20 times) to the concrete across the operating temperature range
Tumble Specification
1000 x 0.5m / 1.64ft. falls at room temperature
ESD
±15KV air discharge, ±8KV conductive discharge
Performance
MCU
Cortex-M3
72MHz
72MHz
Storage
50000 tags
Barcode Scanning
2D Imager Scanner
SE2707
1D Symbologies
UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D Symbologies
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.
Note
*This function is optional
UHF RFID
Engine
CM710-1 module based on Impinj E710
Frequency
920-925MHz / 902-928MHz / 865-868MHz
Impinj Gen2X
Supported
Protocol
EPC C1 GEN2 / ISO18000-6C
Antenna
Linear Polarized antenna (4dBi)
Fastest Read Rate
900+ tags/sec
Max Read Range
26m (Impinj MR6 tag, size 70 x 15mm)
27m (Impinj M750 tag, size 70 x 15mm)
31m (Alien H3 Anti-Metal tag, size 130 x 42mm)
27m (Impinj M750 tag, size 70 x 15mm)
31m (Alien H3 Anti-Metal tag, size 130 x 42mm)
Note
* Ranges are measured in the open outdoors and low interference environment, and rate is measured in a laboratory low interference environment, they are affected by tags and environment.
Support & Downloads
Accessories
Power Adapter-US (R2)
PWR-R2-5V2A-US
Main Battery (R2)
BTRY-R2-52MA
