MC80 5G UHF RFID Reader (Android 16)

Name: MC80 5G UHF RFID Reader (Android 16)
Brand: Chainway
SKU: MC80
Price: 899 USD
Availability: InStock

Chip-Level RFID Integration. One of the First with Android 16. Slimmer Yet More Powerful.

Powered by Qualcomm Dragonwing™ Q-6690, the world's first enterprise mobile processor with fully integrated UHF RFID capabilities, Chainway MC80 is one of the first UHF RFID readers on this platform to ship with Android 16. Featuring a 6-inch display, 5G, Wi-Fi 7, Bluetooth 6.0, and 6 TOPS on-device AI capability, MC80 delivers reliable connectivity and intelligent data processing. With UHF RFID, long-range barcode scanning, NFC, and dual cameras (50 MP rear camera), MC80 provides versatile data capture capabilities across retail, warehousing, logistics, asset management, healthcare, and more.

Starting at $899.00

Adding to order… The item has been added

MC80 5G UHF RFID Reader (Android 16)

Chip-Level RFID Integration. One of the First with Android 16. Slimmer Yet More Powerful.

Chainway MC80 UHF RFID Reader Android 16

Starting at $899.00

features

functions

Specifications

Physical Characteristics

Dimensions

165mm × 76.8mm × 15.5mm / 6.50 × 3.02 × 0.61 in

Weight

283g / 9.98 oz. (device with battery)

Display

6", 720 × 1440 (HD+); optional 1080 × 2160 (FHD+)

Touch Panel

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Power

5000mAh / 8000mAh (optional)
Smart battery supporting QC4.0 and PD3.0 fast charging, with hot-swap capability

Notification

Sound, LED indicator, vibrator

Interfaces

USB 3.0 Type-C, supports OTG and water drop detection
Bottom connector: 6-pin pogo contacts
Rear connector: 2-pin pogo contacts

Card slot

1 Nano SIM + 1 eSIM, 1 TF card

Audio

2 microphones, 1 speaker, 1 receiver

Keypad

1 Power key, 2 scan keys, 1 volume (+/-) keys, 1 multifunctional key

Sensors

G-sensor, light sensor, proximity sensor, geomagnetic sensor, gyro/accelerometer combo sensor

Communication

WLAN

Supports 802.11 a/b/g/n/ac/ax/be (Wi-Fi 7);
2 × 2 MIMO antennas; Fast roaming supported

WWAN (Europe, Asia)

2G: GSM/EDGE/GPRS (850/900/1800)
3G: WCDMA (B1/B5/B8)
4G: LTE-FDD: B1/B3/B5/B7/B8/B20/B28A/B28B/B32
LTE-TDD: B34/B38/B39/B40/B41
5G: N1/N3/N5/N7/N8/N14/N20/N28/N38/N40/N41/N77/ N78/N79

WWAN (America)

2G: GSM/EDGE/GPRS (850/1900)
3G: WCDMA (B2/B4/B5)
4G: LTE-FDD: B1/B2/B3/B4/B5/B7/B12/B13/B14/B25/B26/
B28/B29/B30/B66/B71
LTE-TDD: B38/B40/B41/B48
5G: N1/N2/N3/N5/N7/N12/N13/N14/N25/N26/N28/N29/N30/
N38/N40/N41/N48/N66/N71/N77/N78

Bluetooth

Bluetooth 6.0, BLE, headset support

Vo-LTE

Support VoLTE HD video voice call

GNSS

Integrated GPS, BeiDou, GLONASS, Galileo, and QZSS A-GPS: Supports XTRA
UWB (optional): Enables reliable communication and high-precision positioning in indoor and other complex environments

Developing Environment

Operating System

Android 16 (upgradeable to Android 20)

SDK

Chainway Software Development Kit

Language

Java

Tool

Eclipse / Android Studio

Performance

CPU

Octa-core, 2.0GHz, with an optional configuration of up to 2.9GHz

RAM+ROM

UFS, with configurations ranging from 4GB + 64GB to 16GB + 256GB

Expansion

Supports up to 2T TF card

User Environment

Operating Temp

-4℉ to 122℉ / -20℃ to +50℃

Storage Temp

-40℉ to 158℉ / -40℃ to +70℃

Humidity

5%RH - 95%RH non-condensing

Drop Specification

MIL-STD-810H Drop Test: 1.8m without a protective case and 2.0m with a rugged rubber boot

Tumble Specification

2000 × 0.5m / 1.64ft. falls, IEC compliant

Sealing

Optional IP65/IP67, IEC compliant

ESD

±15kV air discharge, ±8kV contact discharge

Barcode Scanning

2D Scanner

Zebra SE4710/SE4720/SE4770/SE55; CM60

1D Symbologies

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc

2D Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode
Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc

Note

* This function is optional

RFID

Built-in UHF, integrated into the chipset platform

Camera

Front Camera

8MP

Rear Camera

50MP, supports PDAF and HDR, with flash

NFC

Frequency

13.56 MHz
