C90 Mobile Computer (Android 10/14)

Name: C90 Mobile Computer (Android 10/14)
Brand: Chainway
SKU: C90
Price: 429 USD
Availability: InStock

Larger Display, Lighter Weight, Stronger Performance.

Chainway C90 is a rugged handheld computer that exhibits extremely powerful performance. Built with Android 10/14 and a high-performance processor, it features vigorous system configuration. With rich functionality features like barcode scanning, sturdy WiFi performance, NFC, front and rear cameras, it possesses the best price versus performance ratio. All these make C90 immensely perfect to be implemented in a wide spectrum of industries, including logistics, warehousing, retail, healthcare, etc.

Operating System: (*)

Memory: (*)

Charger: (*)

Choose Protection Plan: (*)

Starting at $429.00

Adding to order… The item has been added

C90 Mobile Computer (Android 10/14)

Larger Display, Lighter Weight, Stronger Performance.

features

functions

Specifications

Physical Characteristics

Dimensions

158.5 x 76.0 x 13.1 mm / 6.24 x 2.99 x 0.52 in.

Weight

230g / 8.11 oz. (device with battery)

Display

5.7-inch (18:9), IPS LTPS 1440 x 720

Touch Panel

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Power

Main battery: built-in 5000 mAh
Standby: up to 490 hours (only main battery ; WiFi: up to 470h; 4G: up to 440h)
Continuous use: over 12 hours (depending on user environment)
Charging time: 2.5 hours (charge device by standard adaptor and US

Notification

Sound, LED indicator, vibrator

Interfaces

USB Type-C, USB 2.0, OTG

Card slot

1 slot for Nano SIM card, 1 slot for Nano SIM or TF card

Audio

2 microphones，1 for noise cancellation；1 speaker；receiver

Keypad

Power, 2 scan keys, volume +/-

Sensors

Light sensor, proximity sensor, gravity sensor

Communication

WLAN

Support IEEE802.11 a/b/g/n/ac/d/e/h/i/k/r/v/w, 2.4G/5G dual-band, IPV4, IPV6; Support 5G PA
Fast roaming: PMKID caching, 802.11r, OKC
Operating Channels: 2.4G(channel 1~13), 5G(channel 36,38,40,42,44,46,48,52,56,60,64,100,104,108,112, 116,120,

WWAN (Europe, Asia)

2G: GSM850/GSM900/DCS1800/PCS1900
3G: CDMA EVDO: BC0
WCDMA: B1/B2/B4/B5/B8
TD-SCDMA: A/F(B34/B39)
4G: B1/B2/B3/B4/B5/B7/B8/B20/B34/B38/B39/B40/B41

WWAN (America)

2G: GSM850/GSM900/DCS1800/PCS1900
3G: CDMA EVDO: BC0/BC1
WCDMA: B2/B4/B5/B8
4G: B2/B4/B5/B7/B8/B12/B17/B28A/B28B/B38

Bluetooth

V2.1+EDR,3.0+HS and V4.1+HS, BT5.0

GNSS

GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna

Developing Environment

Operating System

Android 10/14, GMS, FOTA, Soti MobiControl, Android Enterprise Recommended, Zero-Touch, 90-day security updates, SafeUEM supported

SDK

Chainway Software Development Kit

Language

Java

Tool

Eclipse / Android Studio

Performance

CPU

Octa-core 2.0 GHz

RAM+ROM

3GB + 32GB / 3GB + 64GB / 4GB + 64GB

Expansion

Supports up to 256GB Micro SD (TF) card

User Environment

Operating Temp

-20 ℃~+50 ℃

Storage Temp

-40 ℃~+70 ℃

Humidity

5% RH - 95% RH non condensing

Drop Specification

Multiple 1.5 m / 4.92 ft. drops to the concrete across the operating temperature range

Tumble Specification

1000 x 0.5 m/ 1.64 ft. falls at room temperature

Sealing

IP67 per IEC sealing specifications

ESD

±15 KV air discharge, ±8 KV conductive discharge

Barcode Scanning

2D Imager Scanner

Honeywell: N6603 / N6703; CM60

1D Symbologies

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

2D Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc.

Note

*This function is optional

Camera

Front Camera

5 MP

Rear Camera

16MP +2MP Microphotography, Autofocus with flash

NFC

Frequency

13.56 MHz

Protocol

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
