C61 Mobile Computer (Android 11/13)

Name: C61 Mobile Computer (Android 11/13)
Brand: Chainway
SKU: C61--48
Price: 599 USD
Availability: InStock

Easy and Flexible Data Entry, Remarkable Data Capture Performance

Chainway C61 is a new-generation rugged handheld computer. Built with Android 11/13 and Octa-Core processor, it supports 27keys / 37keys / 47keys optional keypad, features 6700mAh removable battery and quick charge, and offers optional trigger handle with extended 5200mAh battery, as well as abundant accessories. And it allows optional barcode scanning, RFID, NFC, etc. With robust data collection capability and high-powered Wi-Fi 6-ready, this mobile computer can perfectly fulfill applications in logistics, warehousing, manufacturing, retail, asset management, etc.

Android Version: (*)

Barcode Scanner: (*)

Pistol Grip: (*)

Keyboard: (*)

Protection Plan: (*)

Starting at $599.00

Adding to order… The item has been added

C61 Mobile Computer (Android 11/13)

Take Efficiency to a New Level

features

functions

Specifications

Physical Characteristics

Dimensions

202.0 x 72.5 x 32.0 mm / 7.95 x 2.85 x 1.26 in.

Weight

13.05 oz. / 370 g(SE4710);
14.25 oz. / 404 g(SE4850);
26.05 oz. / 738 g(SE4850, UHF, pistol battery)
Device Weight for Argentina, Uruguay, Bolivia, Ecuador market: 342~404 g, including battery

Display

4-inch high definition display, 800*480

Battery

6700 mAh removable main battery, 5200 mAh optional pistol battery, support QC3.0 and RTC；Built in 100mAh backup battery, supporting battery hot swap, improving reliability and ensuring user data security
Standby: up to 680 hours (only main batter

Touch Panel

Multi-touch panel, gloves and wet hands supported

Notification

Sound, LED indicator, vibrator

Interfaces

USB Type-C, USB 3.1, OTG, extended thimble

Card slot

1 slot for Mirco SIM card, 1 slot for TF card

Audio

2 microphones, 1 for noise cancellation; 2 speakers; receiver

Keypad

Main keyboard (Optional): 27 keys / 37 keys / 47 keys;
Side keys: 2 SCAN keys + 2 volume keys + 1 user-defined key

Sensors

Accelerometer sensor, light sensor, proximity sensor, gravity sensor

Communication

WLAN

Support 802.11 a/b/g/n/ac/ax-ready/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4,IPV6, 5G PA;
Fast roaming: PMKID caching, 802.11r, OKC;
Operating Channels: 2.4G(channel 1~13), 5G(channel36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132, 13

WWAN (Europe, Asia)

2G: 850/900/1800/1900MHz
3G: CDMA EVDO: BC0
WCDMA: 850/900/1900/2100MHz
TD-SCDMA: A/F(B34/B39)
4G: B1/B3/B5/B7/B8/B20/B38/B39/B40/B41

WWAN (America)

2G: 850/900/1800/1900MHz
3G: 850/900/1900/2100MHz
4G: B2/B4/B5/B7/B8/B12/B13/B17/B28A/B28B/B38

Bluetooth

Bluetooth 5.1

Vo-LTE

Support Vo-LTE HD video voice call

GNSS

GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna

Developing Environment

Operating System

Android 11/13; GMS, 90-day security updates, Android Enterprise Recommended, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported. Committed support for a future upgrade to Android 18 pending feasibility

SDK

Chainway Software Development Kit

Language

Java

Tool

Eclipse / Android Studio

Performance

CPU

Octa-core, 2.0 GHz

RAM+ROM

3 GB + 32 GB / 4 GB + 64 GB

Expansion

Supports up to 256 GB Micro SD (TF) card

User Environment

Operating Temp

-4℉ to 122 ℉ / -20℃ to 50℃
-22℉ to 122℉ / -30℃ to 50℃ (cold storage model)

Storage Temp

-40℉ to 158℉ / -40℃ to 70℃

Humidity

5% RH to 95% RH (non condensing)

Drop Specification

Multiple 1.8 m / 5.9 ft. drops (at least 20 times) to the concrete across the operating temperature range

Tumble Specification

1000 x 0.5 m / 1.64 ft. falls at room temperature

Sealing

IP65 per IEC sealing specifications

ESD

±15 KV air discharge, ±8 KV conductive discharge

Barcode Scanning

2D Imager Scanner

Zebra: SE4710/SE4750SR/SE4750MR/SE4750DP/SE4850; Honeywell: N6603/EX30

1D Symbologies

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

2D Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.

Note

*This function is optional

UHF RFID

Engine

CM710-1 module based on Impinj E710

Frequency

865-868 MHz / 920-925 MHz / 902-928 MHz

Impinj Gen2X

Supported

Protocol

EPC C1 GEN2 / ISO18000-6C

Antenna

Circular Polarized Antenna (4 dBi)

Power

1W (30 dBm, +5 dBm to +30 dBm adjustable)
2W Optional (33 dBm, for Latin America, etc.)

Fastest Read Rate

1300+ tags/sec

Communication Mode

Pin Connector

Max Read Range

27m (Impinj MR6 tag, size70 x 15mm)
26m (Impinj M750 tag, size70 x 15mm)
30m (Alien H3 Anti-Metal tag, size 130 x 42mm)

Note

* Ranges are measured in the open outdoors and low interference environment, and rate is measured in a laboratory low interference environment, they are affected by tags and environment.

Note2

*This function is optional

Camera

Rear Camera

Rear 13 MP Autofocus with flash

NFC

Frequency

13.56 MHz

Protocol

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

Chips

M1 card (S50, S70), CPU card, NFC tags, etc.

Range

2-4 cm

Optional Accessories

Accessories

Separate handle with one button；
Handle + battery (handle battery 5200 mAh, one button) ;
UHF back clip + handle (5200 mAh, one button) ;
Wrist Strap; Charging Cradle

Note

*See details in Accessory Guide
