MC51 5G Built-in RFID Reader (Android 14)
Portable Flexibility for Your Small-Scale RFID NeedsChainway MC51 built-in RFID reader is a powerful 5G handheld terminal featuring a self-developed UHF module based on the Impinj E510 chip. Supporting the latest Impinj Gen2X, it offers outstanding RFID reading capabilities. Designed for industries requiring mobile data capture, the MC51 provides a high-performance processor, 6-inch HD display, and advanced wireless connectivity. Ideal for retail, warehouse management, power inspections, and asset tracking, this versatile device empowers businesses to maximize productivity, and stay ahead in a rapidly evolving world.
MC51 5G Built-in RFID Reader (Android 14)
Portable Flexibility for Your Small-Scale RFID Needs
Chainway MC51 built-in RFID reader is a powerful 5G handheld terminal featuring a self-developed UHF module based on the Impinj E510 chip. Supporting the latest Impinj Gen2X, it offers outstanding RFID reading capabilities. Designed for industries requiring mobile data capture, the MC51 provides a high-performance processor, 6-inch HD display, and advanced wireless connectivity. Ideal for retail, warehouse management, power inspections, and asset tracking, this versatile device empowers businesses to maximize productivity, and stay ahead in a rapidly evolving world.
features
functions
Specifications
Physical Characteristics
Dimensions
161.0 x 77.8 x 15.5mm (Thickest Part: 29.2mm)
6.34 x 3.06 x 0.61 in (Thickest Part: 1.15 in.)
6.34 x 3.06 x 0.61 in (Thickest Part: 1.15 in.)
Weight
323g / 11.39oz. (device with battery)
Display
6-inch high definition display (18:9), 1440 x 720
Battery
5000mAh removable main battery, support QC3.0 and RTC; Support Battery Management System; Hot swap battery backup
Touch Panel
Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
Notification
Sound, LED indicator, vibrator
Interfaces
USB Type-C, USB 3.1, OTG
Card slot
1 for SIM card, 1 for SIM or TF card, Supports eSIM (optional)
Audio
2 microphones, 1 for noise cancellation; 1 speaker; 1 receiver
Keypad
Power key, 2 scan keys, volume (+/-) keys, 1 multifunctional key
Sensors
G_sensor, proximity sensor, light sensor, geomagnetic sensor, gyroscope
Communication
WLAN
Support 802.11 a/b/g/n/ac/ax-6E, 2.4G/5G/6G tri-band, IPV4, IPV6; 2*2 MIMO antennas
Fast roaming: PMKID caching, 802.11r, OKC
Operating Channels: 2.4G (channel 1~13), 5G (channel 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 12
Fast roaming: PMKID caching, 802.11r, OKC
Operating Channels: 2.4G (channel 1~13), 5G (channel 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 12
WWAN (Europe, Asia)
2G: GSM / EDGE / GPRS (850/900/1800)
3G: WCDMA (B1/B5/B8)
4G: FDD-LTE (B1/B3/B5/B7/B8/B20/B28A/B28B)
TDD-LTE (B34/B38/B39/B40/B41)
5G: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78/N79
3G: WCDMA (B1/B5/B8)
4G: FDD-LTE (B1/B3/B5/B7/B8/B20/B28A/B28B)
TDD-LTE (B34/B38/B39/B40/B41)
5G: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78/N79
WWAN (America)
2G: GSM/EDGE/GPRS(850/1900)
3G: WCDMA(B2/B4/B5)
4G: FDD-LTE B2/B4/B5/B7/B12/B13/B25/B26/B28;
TDD-LTE B38/B41;
5G: N2/N3/N5/N7/N12/N13/N25/N26/N28/N38/N41/N77/N78
3G: WCDMA(B2/B4/B5)
4G: FDD-LTE B2/B4/B5/B7/B12/B13/B25/B26/B28;
TDD-LTE B38/B41;
5G: N2/N3/N5/N7/N12/N13/N25/N26/N28/N38/N41/N77/N78
Developing Environment
Operating System
Android 14
SDK
Chainway Software Development Kit
Language
Java
Tool
Eclipse / Android Studio
Performance
CPU
Qualcomm Octa-core, 2.4GHz
RAM+ROM
UFS: 4GB + 64GB / 6GB + 128GB (optional) / 8GB + 128GB (optional) / 8GB + 256GB (optional)
Expansion
Supports up to 256GB TF card (Supports Extreme Micro SD Card 512GB)
User Environment
Operating Temp
-4°F to 122°F / -20℃ to +50℃
Storage Temp
-40°F to 158°F / -40℃ to +70℃
Humidity
5% RH - 95% RH non condensing
Drop Specification
Multiple 1.5m / 4.92ft. drops to the concrete across the operating temperature range
MIL-STD-810H (SGS Test): Multiple 1.5 m/4.92 ft. drops to concrete across the operating temperature range
MIL-STD-810H (SGS Test): Multiple 1.5 m/4.92 ft. drops to concrete across the operating temperature range
Tumble Specification
1000 x 0.5m / 1.64ft. falls at room temperature
Sealing
IP67 per IEC sealing specifications
ESD
±15 KV air discharge, ±8 KV conductive discharge
Barcode Scanning
2D Scanner
Zebra: SE4710; SE5500; CM60
1D Symbologies
UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D Symbologies
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc.
Note
* This function is optional
UHF RFID
Engine
CM-5N module based on Impinj E510
Frequency
865-868 MHz / 920-925 MHz / 902-928 MHz
Impinj Gen2X
Supported
Protocol
EPC C1 GEN2 / ISO18000-6C
Antenna
Circular Polarized Antenna (0 dBi)
Power
+5dBm to +30dBm adjustable
Max Read Range
4m
Note
* Ranges are measured in the open outdoors and low interference environment, and rate is measured in a laboratory low interference environment, they are affected by tags and environment.
* Built-in UHF version does not support pistol
* Built-in UHF version does not support pistol
Camera
Front Camera
5MP
Rear Camera
16MP Autofocus with flash
Optional Accessories
Accessories
USB Cable, Adapter, Charging Cradle, etc.
Note
*See details in accessory guide
