CM710-4 UHF RFID Module (4-Port)
Based on Impinj E710, 77.2 x 51.0 x 8.9 mmChainway CM710-4 is a 4-Port RFID module based on Impinj E710 chip that can be used in fixed RFID readers. With the support of Impinj Gen2X, this module provides superior UHF performance. This reliable module is small in size, low in power consumption, and high in stability. It is also resistant to electromagnetic interference and good at heat dispersion. The module appeals to challenging industries like warehousing, logistics, apparel, production lines and such.
CM710-4 UHF RFID Module (4-Port)
Based on Impinj E710, 77.2 x 51.0 x 8.9 mm
Chainway CM710-4 is a 4-Port RFID module based on Impinj E710 chip that can be used in fixed RFID readers. With the support of Impinj Gen2X, this module provides superior UHF performance. This reliable module is small in size, low in power consumption, and high in stability. It is also resistant to electromagnetic interference and good at heat dispersion. The module appeals to challenging industries like warehousing, logistics, apparel, production lines and such.
features
functions
Specifications
Physical Characteristics
Dimensions
77.2 mm x 51.0 mm x 8.9 mm
Weight
52.0 g / 1.83 oz.
RFID Features
RF Chip
Impinj E710
Air Interface Protocol
EPCglobal Gen2 ( ISO18000-6C )
Supports Impinj Gen2X
Supports Impinj Gen2X
Working Frequency
865-868 / 920-925 / 902-928 MHz ( custom-design for frequency band )
Output Power
5-30dBm adjustable; 1dB step interval; +/- 1dB precision
Output Power Flatness
+/- 0.2dB
Antenna Interface
4-channel 50Ω RF connector SMA receptacle
Regions Supported
FCC 902-928 MHz
ETSI 865.6-867.6 MHz
China 920-925 MHz;
Others for customization ( 865-868, 902-928 MHz )
ETSI 865.6-867.6 MHz
China 920-925 MHz;
Others for customization ( 865-868, 902-928 MHz )
Receive Sensitivity
< -86 dBm
Tag RSSI
Supported
Antenna Detector
Supported
Ambient Temp Monitor
Supported
Working Mode
Single / DRM
Communication Interface
Connector
15 PIN W-TO-B Connector
Host Communication
UART 3.3V TTL Level
Baud Rate: 115200bps
Baud Rate: 115200bps
Power Supply
Input Voltage
DC 3.5-5.25V
Power Consumption in RF Output Mode
7.5W
Power Consumption in Standby Mode（EN high TTL level）
0.175W
Power Consumption in Power Down Mode（EN low TTL level）
42.5μW
User Environment
Operating Temp
-13 °F to 149 °F / -25℃ to 65℃
Storage Temp
-40 °F to 185 °F / -40 °C to 85 °C
Humidity
10% - 95%
Reading Performance
Reading Rate
950+ tags/s
Reading Range
Up to 10m ( with 4dBi antenna )
